| Parameter/ Personalized setting | Particular configuration | |||
| Airflow (m3/h) | 15200 | |||
| Air outlet direction | Side | Sunshine-proof PP cover/stainless steel column |  |
|
| Engineering noise (dB) | ≤ 63 | AC single phase 3 speed asynchronous motor ( double motor ) | |
|
| Operating range (°C) | -20~55 | 4 nylon fan blades ( double blades ) | |
|
| Voltage/frequency (V/Hz) | 220/50 | 5090 high effect cooling pads (back air inlet) | |
|
| Power (kW) | 0.56 | 4090 high effect cooling pads (left/right air inlet) | |
|
| Control model | Digital panel/remote control | Left and right electric swing air outlet(manual up and down) | |
|
| air volume mode | 3-speeds | 120L plastic water tank/Embedded water gauge | |
|
| Body length/width/height | 910*490*2190 | PVC water pipe | |
|
| Packaging Size (mm ) | 920*490*2200 | Open type water diversion plate | |
|
| Net weight (Kg) | 64 | Flame retardant electrical box | |
|
| Outlet Size (L*H) (mm) | 600*640 | 3 speed controller(moisture-proof treatment/up and down control) | |
|
| Air supply distance (m) | 11 | 10m remote control | |
|
| Storage tank volume (L) | 120 | Manual drain outlet | |
|
| Evaporation rate (%) | ~92 | Floating water inlet valve | |
|
| Refrigeration setting | |
Manual water inlet | |
|
| Ventilation setting | |
Rocker type water sensor | |
|
| Left and right auto swing setting | |
Ceramic shaft circulating water pump | |
|
| Incoming call automatic recovery | |
5m national standard power supply wire | |
|
| 1-8 Hours time shut down | |
All stainless steel screws(fasteners) | |
|
| UV sterilization | after cooling | Fan protection steel mesh | |
|
| Motor limit electric current protection | |
PP dustproof net | |
|
| UV water processor |  |
4 inch rotating caster with brake | |
|
| Over temperature protection of circulating water pump | |
Water shortage protection of circulating water pump | |
Butterfly CoolCross Fridge
Double controller and double outlet / 3 speeds / Electronic panel / 120L big water tank / Nylon 4 blade / High quality silent fan / 100% new PP shell / Pure copper motor / Odor-free cooling pad / strong wind / energy saving / 5 meters Cable winding storage / 10-meter remote control / 1-8 hour Delayed Shutdown / quick pipe connect / Water-drop wind bar / Dust-proof filter / Swivel caster with brake / Stainless steel screws / Evaporation rate >92 ％ / UV germicidal lamp+ Circulating water pump(optional)
Specifications:
- Airflow : 15200 m3/h
- Power / Voltage : 0.56Kw / 220V
- Fan Speed : 3 speeds
- Wind Distance : 11m
- Water Capacity : 120L
- Size (cm) : 91*49*219
- 20GP : 28(CBU)
- 40HQ : 58(CBU)/75(SKD)
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 1 × 1 × 1 cm |
| Airflow (m³/h) | 15200 |
| Power (KW) | 0.56 |
| Area (m²) | 120 |
| Product Type | Mobile type |
Specifications:
- Airflow : 15200 m3/h
- Power / Voltage : 0.56Kw / 220V
- Fan Speed : 3 speeds
- Wind Distance : 11m
- Water Capacity : 120L
- Size (cm) : 91*49*219
- 20GP : 28(CBU)
- 40HQ : 58(CBU)/75(SKD)
| Weight | 1 kg |
|---|---|
| Dimensions | 1 × 1 × 1 cm |
| Airflow (m³/h) | 15200 |
| Power (KW) | 0.56 |
| Area (m²) | 120 |
| Product Type | Mobile type |
