| Parameter/ Personalized setting | Particular configuration | |||
| Largest airflow (m³/h) | 25000 | Sunshine resist PP machine cover (100% new material) |  |
|
| Air outlet direction | Down | AC three-phase 220V asynchronous motor | |
|
| Engineering noise (dB) | ≤78 | 9 nylon fan blades | |
|
| Net weight (KG) | 68 | 5090 high-efficiency cooling pad | |
|
| Operating range (°C) | -20 ~ 55 | Cooling pads protective cover | |
|
| Motor insulation | F/IP64 | PVC water pipe | |
|
| Voltage/frequency (V/Hz) | 220/50 | Open-type water diversion plate | |
|
| Power (kW) | 1.5 | Flame retardant electrical box | |
|
| Controller/air volume mode | LCD panel/remote control/60 speed | LCD screen control panel | |
|
| Body length/width/height | 1080*1080*1270 | 10m remote control | |
|
| Mounting foot size (mm) | 970*970 | Temperature and humidity sensor |  |
|
| Dimensions of flanged outlet (mm) | 670*670 | Remote install pedestal | |
|
| Current (A) | 9 | Floating water inlet valve | |
|
| Enter water pipe diameter (mm) | ϕ20 | Manual water inlet | |
|
| Blowdown diameter (mm) | ϕ32 | Barrier free drain pump | |
|
| Storage tank volume (L) | 25 | Ceramic shaft circulating water pump | |
|
| Pipeline air supply distance (m) | 40 | 15m national standard signal wire | |
|
| Direct air supply distance (m) | 28 | 4m national standard power supply wire | |
|
| Evaporation rate (%) | ≈92 | Fan steel stainless support pole | |
|
| Suitable area (m²) | 80-200 | All stainless steel screws (fasteners) | |
|
| Fault code prompt | |
Galvanize air duct flange (connector) | |
|
| Fully automatic operation mode | |
Steel net flange (suggest optional spare part) | |
|
| Refrigeration setting | |
Steel stainless gauge element bracket | |
|
| Ventilation setting | |
UV water processor | |
|
| Manual cleaning setting | |
PP dustproof net | |
|
| Left and right auto swing setting | Need equip electric air diffuser |
Primary filter cotton frame | |
|
| Automatic blowdown setting (default 8 hours) | 0~7.2L/hour/time | Motor limit electric current protection | |
|
| Incoming call automatic recovery | |
Water shortage protection of circulating water pump | |
|
| UV sterilization | after cooling |
Over-temperature protection of circulating water pump | |
|
| Smart / (OUBER+) | |
Over/under voltage protection | |
FAD25-IQ
Down air outlet / 60 speeds / LCD Touch panel / 25L water tank / Nylon 9 blade / High quality silent fan / 100% new PP shell / Pure copper motor / 5090 high effect cooling / strong wind / energy saving / 15-meter remote control / 1-8 hour Delayed Shutdown / quick pipe connect / power-on-reset / auto self-cleaning / sealed circuit board / Wide adjustable range / Stainless steel screws / Evaporation rate >92 ％ / Dust-proof filter（optional） / UV germicidal lamp+ Circulating water pump(optional) / Smart (OUBER+)
Specifications:
- Airflow : 25000 m3/h
- Power / Voltage : 1.5Kw / 220V
- Fan Speed : 60 speeds
- Duct /Direct Distance : 40m / 28m
- Water Capacity : 25L
- Size (cm) : 108*108*127
- 20GP : 10(CBU)/30(SKD)
- 40HQ : 44(CBU)/77(SKD)
Additional information
| Weight | 68 kg |
|---|---|
| Dimensions | 108 × 108 × 127 cm |
| Airflow (m³/h) | 25000 |
| Area (m²) | 200 |
| Power (KW) | 1.5 |
| Product Type | Fixed type |
Specifications:
- Airflow : 25000 m3/h
- Power / Voltage : 1.5Kw / 220V
- Fan Speed : 60 speeds
- Duct /Direct Distance : 40m / 28m
- Water Capacity : 25L
- Size (cm) : 108*108*127
- 20GP : 10(CBU)/30(SKD)
- 40HQ : 44(CBU)/77(SKD)
| Weight | 68 kg |
|---|---|
| Dimensions | 108 × 108 × 127 cm |
| Airflow (m³/h) | 25000 |
| Area (m²) | 200 |
| Power (KW) | 1.5 |
| Product Type | Fixed type |
