| Parameter/ Personalized setting |
|
|
Particular configuration |
|
| Largest airflow (m³/h) |
4000 |
|
Sunshine-proof PP cover / stainless steel column |
 |
| Air outlet direction |
Side |
|
BLDC motor |
|
| Engineering noise (dB) |
≤64 |
|
4 nylon fan blades |
|
| Operating range (°C) |
-20 ~ 55 |
|
5090 high efficiency cooling pads (back air inlet) |
|
| Voltage/frequency (V/Hz) |
220/50 |
|
4090 high efficiency cooling pads (left/right air inlet) |
|
| Power (kW) |
0.32 |
|
Left & right electric swing air outlet (manual up & down) |
|
| Control model |
Digital touch panel / remote control |
|
120L plastic water tank with embedded water gauge |
|
| Air volume mode |
Direct current inverter 9 speed |
|
PVC water pipe |
|
| Body size (L×W×H ) (mm) |
910× 490× 1380 |
|
Open type water diversion plate |
|
| Packaging size (mm) |
920× 490× 1280 |
|
Flame retardant electrical box |
|
| Net weight / Gross weight (kg) |
38/ 43 |
|
9 speed moisture-proof treatment |
|
| Outlet size (H×H mm) |
600× 640 |
|
Manual drain outlet |
|
| Air supply distance (m) |
13 |
|
Floating water inlet valve |
|
| Storage tank volume (L) |
120 |
|
Manual water inlet |
|
| Evaporation rate (%) |
≈92 |
|
Ceramic shaft circulating water pump |
|
| Refrigeration setting |
|
|
Rocker type water sensor |
|
| Ventilation setting |
|
|
5m national standard power supply wire |
|
| Temperature display |
|
|
All stainless steel screws (fasteners) |
|
| Left & right auto swing setting |
|
|
Fan protection steel mesh |
|
| Fully automatic temperature control speed function |
|
|
PP dustproof net |
|
| 3D natural wind function |
|
|
4 inch rotating caster with brake |
|
| Child lock function |
|
|
Water shortage protection of circulating water pump |
|
| Light off |
|
|
Over temperature protection of circulating water pump |
|
| 1–8 hours timer shut down |
|
|
Motor limit electric current protection |
|
| UV sterilization |
after cooling  |
|
UV water processor |
|
